Commercial And Industrial Energy Storage System
-
40-feet Air-cooled cabinet
This system is designed using a 40 feet container to facilitate subsequent power expanion
Configure EMS management system
Adoopting air-cooled air conditioning temperature control
Configure EMS management system
Adoopting air-cooled air conditioning temperature control
-
Feature and Application:
This system is designed using a 40 feet container to facilitate subsequent power expanion
Configure EMS management system
Adoopting air-cooled air conditioning temperature control
Main parameters:
System current:3.44MWh
Output power:630KW
Output voltage:AC380V/AC400V 3W+N+PE
System DC voltage: DC768V
System capacity:4480Ah
Size: 12192*2438*2591mm
System parametersBattery type 3.2V/280Ah System battery configuration 16P240S Battery rated capacity 3440KWh Battery voltage range 672-864V BMS communication interface Ethernet BMS communication protocol Modbus TCPbus System parameters Converter dimensions (L*W*H) L1600*H2096*W935mm Container Dimensions (L*W*H) L12192*W2438*H2591 Weight of container 32T Protection level IP54 Operating temperature range (-30°℃~50°℃) (>45°℃Reduction) Operating humidity range 0~95% (No condensation) Battery temperature control mode Intelligent air–cooled Cooling mode of converter Temperature control forced air cooling Fire fighting system (battery container) Aerosol, flammable gas detection + exhaust, water fre (optional) System communication interface RS485、Ethernet、CAN External system communication protocol Modbus TCP、 Modbus RTU、 CAN2.0
