Long Life Series
-
Long Life Battery Series
Voltage :6V &12V
Capacity :40AH to 250AH
ServiceLife: Battery floating service life can target 15 years at 20oC/68oF to25oC677oF
General Features
• Nonspillable •Sealed and Maintenance-free Operation •High Quality and High Reliability •Exceptional Deep Discharge Recovery •Low Self-discharge •Long Service Life •Solid Copper Terminals •Tank-formed Plates •Computer-aided Design and Manufacturing •UL, CE, VdS Approved
Typical Applications
•Telecommunication equipment •Electronic instruments •UPS systems •Solar power system •Wind Power system
Capacity :40AH to 250AH
ServiceLife: Battery floating service life can target 15 years at 20oC/68oF to25oC677oF
General Features
• Nonspillable •Sealed and Maintenance-free Operation •High Quality and High Reliability •Exceptional Deep Discharge Recovery •Low Self-discharge •Long Service Life •Solid Copper Terminals •Tank-formed Plates •Computer-aided Design and Manufacturing •UL, CE, VdS Approved
Typical Applications
•Telecommunication equipment •Electronic instruments •UPS systems •Solar power system •Wind Power system
-
General Technical Specifications
We are updating the datasheet now. Pls contact the concerned person for details.Model Nominal
Voltage
(V)Capacity
(AH)Internal
Resistance
(mOhm)Dimensions（mm/in） Terminal Weight
±4%(Kg)Length Width Height Total Height mm in mm in mm in mm in Type Position Kg Lbs FP685L 6 8.5 8 151 5.94 34 1.34 94 3.70 100 3.94 T1/T2 F 1.35 3.0 FP1270L 12 7 28 151 5.94 65 2.56 94 3.70 100 3.94 T1/T2 F 2.35 5.18 FP1290L 12 9 19 151 5.94 65 2.56 94 3.70 100 3.94 T1/T2 F 2.65 5.84 FP12120L 12 12 19 151 5.94 98 3.86 95 3.74 101 3.98 T2 F 3.6 7.94 FP12170L 12 17 16 181 7.13 77 3.03 167 6.57 167 6.57 T3/T8 D 5.25 11.6 FP12180L 12 18 16 181 7.13 77 3.03 167 6.57 167 6.57 T3/T8 D 5.45 12.02 FP12240L 12 24 14 166 6.54 175 6.89 125 4.92 125 4.92 T3/T8 D 7.9 17.42 FP12280L 12 28 10 8.7 19.18 LFP6200L 6 200 3.1 321 12.64 176 6.93 226 8.90 246/229 9.69/9.02 T5/T11 A 32 70.55 LFP1240L 12 40 8.5 197 7.76 165 6.50 170 6.69 170/170 6.69/6.69 T4/T9 D 13.5 29.76 LFP1250L 12 50 7.5 229 9.02 138 5.43 208 8.19 230/211 9.06/8.31 T5/T9 C 17 37.48 LFP1255L 12 55 6.5 17.8 39.24 LFP1250AL 12 50 7.5 258 10.16 133 5.24 200 7.87 200 7.87 T9 C 16.5 36.38 LFP1265L 12 65 6.5 350 13.78 167 6.57 179 7.05 186/179 7.32/7.05 T5/T9 C 22 48.50 LFP1260L 12 60 7 260 10.24 168 6.61 211 8.31 233/214 9.17/8.43 T5/T9 C 21 46.30 LFP1270L 12 70 6.5 23 50.71 LFP1280L 12 80 5.4 25 55.12 LFP1290L 12 90 5.5 306 12.05 169 6.65 211 8.31 233/214 9.17/8.43 T5/T9 C 28 61.73 LFP12100L 12 100 4.5 330 12.99 171 6.73 214 8.43 224/220 8.82/8.66 T5/T9 C 32 70.55 LFP12120L 12 120 4 409 16.10 176 6.93 225 8.86 225/225 8.86/8.86 T5/T11 C 37 81.57 LFP12150L 12 150 3.5 485 19.09 172 6.77 240 9.45 242/240 9.53/9.45 T5/T11 C 46 101.41 LFP12200L 12 200 3 522 20.55 238 9.37 218 8.58 238/221 9.37/8.7 T5/T11 E 65 143.30 LFP12250L 12 250 2.6 521 20.51 269 10.59 220 8.66 242/223 9.53/8.78 T5/T11 E 78 171.96 LFP1230FT 12 30 9.5 225 8.86 98 3.86 225 8.86 225 8.86 T9 E 10.5 23.15 LFP1250FT 12 50 7.5 277 10.91 106 4.17 221 8.70 221 8.7 T9 E 15 33.07 LFP1255FT 12 55 6.5 16 35.27 LFP1275FT 12 75 6 562 22.13 114 4.49 189 7.44 189 7.44 M8 bolt E 25 55.12 LFP12100FT 12 100 5 506 19.92 110 4.33 224 8.82 239 9.41 T9 E 31 68.34 LFP12100-AFT 12 100 4.2 395 15.55 110 4.33 286 11.26 286 11.26 T9 E 35 77 LFP12100BFT 12 95 4.8 390 15.35 105 4.13 265 10.43 265 10.43 T9 E 27 59.52 LFP12105FT 12 105 6 395 15.55 110 4.33 286 11.26 286 11.26 T9 E 32 70.55 LFP12110FT 12 110 5 32.5 71.65 LFP12110AFT 12 110 4.5 560 22.05 125 4.92 228 8.98 228 8.98 T9 E 33 72.75 LFP12120FT 12 120 4.3 551 21.69 110 4.33 239 9.41 239 9.41 T11 E 36 79.37 LFP12125FT 12 125 4.2 436 17.17 108 4.25 317 12.48 317 12.48 T14 E 38 83.78 LFP12150FT 12 150 4 551 21.69 110 4.33 287 11.30 287 11.3 T11 E 45.5 100.31 LFP12150.AFT 12 150 4 551 21.69 110 4.33 287 11.30 287 11.3 T11 E 50 110 LFP12150FTT 12 165 4 546 21.5 125 4.92 317 12.48 323 12.72 T11 E 50 110.2 LFP12170FT 12 170 4 546 21.50 125 4.92 317 12.48 323 12.72 T11 E 54 119.05 LFP12180FT 12 180 3.8 56 123.46 LFP12155KFT 12 155 4 560 22.05 126 4.96 280 11.02 280 11.02 T11 E 49 108.03 LFP12180KFT 12 180 3.6 53 116.84 LFP12200FT 12 200 3.2 546 21.50 125 4.92 317 12.48 323 12.72 T11 E 59 130.07
VRLA (AGM) Battery
